Tracked-Mounted Mobile Impact Crusher

Tracked-Mounted Mobile Impact Crusher

Mobile Impact Crusher  of Liming heavy industry is based the latest manufacturing technology,It has been widely used in many industries,Mobile Impact Crusher is worthy of your trust.

Tracked-Mounted Mobile Impact Crusher

Mobile Impact Crusher’s introduction:

The tracked Mobile Impact Crusher (also called crawler mobile impact crusher or pedrail

mobile impact crusher) is powered by a fuel-efficient compliant diesel engine. The Mobile Impact Crusher is the star product of kefid. Mobile Impact Crusher is manufactured with the latest manufacturing technology, using the high-quality and high-chromium plate hammer and wear-resistance impact lining plate. The large crushing ratio plus the impact crusher’s inherent characters, which can produce final products with good-quality particle shape, contribute to making the mobile crushing unit have a wider application range.

Mobile Impact Crusher’s Features:

1. World-level manufacturing technology is adopted, and highest-level raw material is used.

2. Central lubricating device are installed on the machine, so the bearing is easy to be lubricated.

3. Adjustment of the discharge part is more convenient.
The adjustment methods: gasket adjustment, hydraulic assistant adjustment, wedge block and wedge hydraulic adjustment.

4. More advanced movable jaw assembly lengthens life of crusher.
Movable jaw assembly is made from cast piece with high-quality, is driven by two large flying wheels which are made from cast steel. Moreover, heavy eccentric shaft is processed by forged mold. All of these make the JC series jaw crusher extremely reliable.

5. Integral cast steel structure is adopted for bearing seat. Integral cast steel bearing matches well with the crusher frame, at the same time, radial strength of the bearing seat is highly strengthened. However, the separate bearing seat does not have this advantage.

6. Finite element analysis technology is adopted to make the crusher much stronger.

7. Crusher chamber adopts “V” structure which could make actual feed width comply with the nominal one.

8. Bearing with larger model and higher load are used. All JC jaw crusher is equipped with larger bearing compared with same model of normal jaw crusher. Its higher load capacity and effective oil seal will lengthen the life of bearing.

9. A newly designed tooth-shape side plate, makes the available area of jaw plate longer, and enhances the capacity.

10. Pressing bar and support type are used to fix jaw plate.

11. Heavy type protecting plate is intalled for bearing seat, accidental damage of bearing seat is avoided.

12. Supporting bar under jaw plate protects movable jaw and frame from being worn down.

Mobile Impact Crusher’s  Highlights:

(1) Integrated machine set with the impact crusher series mobile crusher.

(2) This mobile impact crusher is designed to be of high flexibility.

(3) Lower transportation cost our customs will pay.

(4) High efficiency

(5) The mobile impact crusher is easy to adjust and to collocate

(6) Reliable performance and convenient maintenance.

Mobile Impact Crusher’s Working principle:

Mobile impact crusher is a new designed mobile crushing & screening plant, which is flexible, convenient and strong in mobility, so this series mobile crusher can save a large construction capital and relocation. Raw Materials can be broken by the impact crusher and other crushing equipment of the mobile crushing plant at the locale without being transported again, and also can be moved with the promotional exploitation of the raw material, which saves a large number of transportation costs.

The Mobile Impact Crusher (mobile crushing and screening plants) is composed of primary crushing and screening station and secondary one, belt conveyor, etc. Every mobile crusher station is an independent working unit, they can respectively assume their different responsibility, and the belt conveyer is responsible for material transmitting and piling up between each mobile crusher station.

Mobile Impact Crusher’s Specifications:

Technical Data\Model YG938 FW1214Ⅱ YG1142 FW315Ⅱ YG1349 FW318Ⅱ
Transportation size(mm) 11900×2650×3850 13500×2780×4150 15200×2950×4300
Weight(t) 41 52 61
Tire Configuration Dualaxial Triaxial Triaxial
Impact Crusher PFW-1214Ⅱ PFW-1315Ⅱ PFW-1318Ⅱ
The Maximum Feeding Size(mm) 500 600 700
Capacity(t/h) 130~200 180~320 240~400
Vibrating Feeder GZD960×3800 GZD1100×4200 GZD1300×4900
Main Belt Conveyor B800×8.5M B1000×9M B1200×9.5M
Side Belt Conveyor (optional) B450×3M B500×3.5M B650×4M
Electric control standard control box + control panel control box + control panel control box + control panel
optional Control box + LCD Control box + LCD Control box + LCD
Hydraulic leg standard 4 4 4
optional 2 2 2
Hydraulic cyclinder standard 4 4 4
optional 5 5 5
Genset (optional) (Kw) 270 380 440
Iron Separator (optional)(Kw) RCYD(C)-8 RCYD(C)-10 RCYD(C)-12

Any change of technology data shall not be advised additionally.

Mobile Impact Crusher’s Applications:

1.Mobile Impact Crusher can be used in construction waste

Mobile Impact Crusher can be used in construction waste. Arbitrary movement of equipment can make it near the processing site, which can reduce transportation costs and avoid pollution again. Constructions waste recycling in the closed workshop, solve varieties of pollutions. Producing a variety of recycled aggregate, and achieves zero emission. Recycling construction waste can achieve economic, social and ecological benefits.

2. Mobile Impact Crusher can be used in basalt crushing

Basalt is the best stone materials used in the repair of roads, railways, airport runways. Basalt mine is of strong compression, low crushing value, strong corrosion resistance, etc. Basalt ore by adhesion of asphalt is of lots of advantages, such as wear resistant, strong compression, strong corrosion resistance, etc. And this is internationally recognized that basalt ore is the best foundation to develop rail transport and road transport. Mobile Impact Crusher can be used in basalt crushing.

 3. Mobile Impact Crusher can be used in crushing iron ores

Iron ores are rocks and minerals from which metallic iron can be economically extracted. Iron is the world’s most commonly used metal – steel, of which iron ore is the key ingredient, represents almost 95% of all metal used per year. It is used primarily in structural engineering applications and in maritime purposes, automobiles, and general industrial applications  .
