CS series Cone crusher is a modern high-performance Symons cone crusher or symons crusher, which is developed based on laminated smashing principle and conceptual design of “more crushing and less grinding” according to users’ demands.
CS Series Cone Crusher’s introduction
CS series Cone crusher has more reasonable and perfect structure and more advanced technology. It is excellent in manufacturing, installing, applying and maintaining etc.
The design CS cone crusher was as simple as possible with features that were user friendly, and craftsmen with many years of experience built the frames and components .it used in construction gravel, sand making process plant, especially broken basalt and other hard materials, high efficiency and low production costs.
CS Series Cone Crusher’s Features:
1. World-level manufacturing technology is adopted, and highest-level raw material is used.
2. Central lubricating device are installed on the machine, so the bearing is easy to be lubricated.
3. Adjustment of the discharge part is more convenient.
The adjustment methods: gasket adjustment, hydraulic assistant adjustment, wedge block and wedge hydraulic adjustment.
4. More advanced movable jaw assembly lengthens life of crusher.
Movable jaw assembly is made from cast piece with high-quality, is driven by two large flying wheels which are made from cast steel. Moreover, heavy eccentric shaft is processed by forged mold. All of these make the JC series jaw crusher extremely reliable.
5. Integral cast steel structure is adopted for bearing seat. Integral cast steel bearing matches well with the crusher frame, at the same time, radial strength of the bearing seat is highly strengthened. However, the separate bearing seat does not have this advantage.
6. Finite element analysis technology is adopted to make the crusher much stronger.
7. Crusher chamber adopts “V” structure which could make actual feed width comply with the nominal one.
8. Bearing with larger model and higher load are used. All JC jaw crusher is equipped with larger bearing compared with same model of normal jaw crusher. Its higher load capacity and effective oil seal will lengthen the life of bearing.
9. A newly designed tooth-shape side plate, makes the available area of jaw plate longer, and enhances the capacity.
10. Pressing bar and support type are used to fix jaw plate.
11. Heavy type protecting plate is intalled for bearing seat, accidental damage of bearing seat is avoided.
12. Supporting bar under jaw plate protects movable jaw and frame from being worn down.
CS Series Cone Crusher’s Highlights:
(1) High-performance
Combining optimal designing of chamber type with applying reasonable speed and stroke, to make this kind of machine does more work with the same dynamic cone diameter. Therefore, this machine is of high-performance and manufacturing capacity compared with other cone crusher of the same type. Use laminated crushing principle, to make more cubic shape materials and less needle-like materials.
(2) Good products size composition
The crusher applies for laminated crushing principle to make cubic shapes of final products stand for larger proportion. Acicular and flake shape products decrease and size fraction much more well-proportioned.
(3) Good stability
If there is metal or other non-broken material come to the chamber, metal going through protection device will release it and then reset automatically. The protection device has fixed discharge opening returning point and the original discharge opening can returning back immediately after the metal goes through the crushing chamber.
(4) Convenient Cleaning-up
If the crusher stops under loading condition, hydraulic cleaning system can clean up the crushing chamber quickly so that decrease the downtime.
(5) High reliability.
Adopting main shaft with big diameter，heavy main frame and separate automatic Control System of thin oil lubrication system, so that it guarantees robustness and reliable operation of the crusher.
(6) Easy maintenance and operation
All parts can be disassembled from top and the upper side, so that fixed cone and dynamic cone can be disassembled easily. Under high shock and vibration environment, bronze Bearing can keep excellent bearing capacity and it is much more economic and easy for maintenance.
(7) Low production costs
Due for big capacity, high reliability and easy maintenance, the production costs has been reduced greatly.
(8) Widespread use
CS series Cone crusher is characterized by maximizing the performance to apply to all kinds of crushing process: from special coarse crushing to fine crushing; from fixed crushing plant to mobile crushing plant. CS Series Cone Crusher has different types of crushing chamber for choosing according to crushing process.
CS Series Cone Crusher’s Working principle:
Through the v-belts, pulley, transmission shaft, pinion and the bevel gear, the power will be transmitted from the electrical motor to the eccentric bushing. Thus the eccentric bushing begins to rotate, which will generate the friction force to drive the main shaft rotating and wiggling. Therefore, part of the mantle approaches the bowl liner to crush the material, while the other part of the mantle is a little bit far from the blow liner, between which the crushed products of required size will be discharged from the lower part after repeating crushing, extruding and bending.
CS Series Cone Crusher’s Applications:
1. Used in dolomite crushing
Dolomite is the main mineral component composed of dolomite and dolomite limestone. The dolomite can be used in building materials, porcelain, glass and refractory after dolomite crushing. In chemical industry, agriculture, environmental protection, energy conservation, etc, the dolomite is in a great demand too and so the dolomite crusher is widely applied. The dolomite is mainly used as the flux of Basic Refractories and blast furnace. In the whole, the CS series cone crusher is typically used.
2. Used in petroleum coke crushing
CS Series Cone Crusher is always used for the petroleum coke delivery/crushing operation for the electric power plant. The coke is delivered in a very wet condition and the bottom of the rail cars is usually dripping water. The coke is then lifted up to the roof of a very large barn and dumped onto the floor of the barn. The pile on the floor is allowed to remain there to drain the excess water. A front end loader takes the coke from the pile and dumps it into a crusher feed hopper where the large pieces are crushed in preparation for delivery into the boiler burner. In the operation, CS Series Cone Crusher is your best choice.
3. Used in river pebbles crushing
River pebbles are a natural stone, the main ingredient is silica, but also contains iron oxide, manganese, copper, aluminum and other elements and compounds. River pebble is hard, with compression, wear resistant and other natural features, is an ideal green building material, and is widely used in building and road construction and other industries. Before river pebbles apply to various industries, it must be broken, to achieve the right size to be used. CS Series Cone Crusher can be effective crushing for river pebbles.
