Introduction of 350tph granite sand technology

Processing materials: granite, limestone yield: 350t/h

Material granularity: 0-5mm, 5-10mm, 10-20mm, 20-31.5 mm

Application: stirring station, highway

Equipment configuration: vsi6x sand machine, GZD1100 * 4200 vibrating feeder, PE750 * 1060 jaw crusher, HPT300 hydraulic cone crusher, 5X9532 sand machine, YZS2460 shaker, YZS 2160 vibration sieve

According to the customer’s requirements, we can give customer configuration PE1200 * 1500 jaw crusher, hydraulic cone crusher HPT300 two crusher, after the large stone into the bunker, through GZD1100 * 4200 vibrating feeder into PE750 * 1060 jaw crusher, and then by belt conveyor after the break at the beginning of the stone into secondary crushing HPT300 hydraulic cone crusher, cone break after discharge by the vibrating screen to sieve, the return of more than 40 mm cone broken again, adjust the storehouse is less than 40 mm material into three speaks of interim positions, and then enter the 5 x9532 system sand machine was broken, the finished product into the vibrating screen for screening.

After screening, the grain size is 0 — 5mm, 5-10mm, 10-20mm, 20-31.5 mm of stone is produced by the belt machine, and the stone material of more than 31.5 mm is directly entered into the sand making machine and it is broken again.
